Description
Charging Output:
Over-discharge of the battery can be prevented by connecting all loads to the charging output. This output will disconnect the load when the battery has discharged to a preset voltage.
Some loads (especially inverters) are best connected directly to the battery, and the inverter’s remote control to the charging output. A special interface cable may be required; please refer to the manual.
The connection and disconnection voltages are adjustable.
Day/Night Programming of the Charging Output
This option allows you to preset the ON time after dusk.
Programmable Battery Charging Algorithm
Pre-programmed algorithms for AGM, GEL, flooded, or LiFePO4 batteries (only with an internal BMS).
Two 5-volt USB Outputs
Maximum current (both outputs combined): 2A
